** IN-BUILD ** 2024 FUSO Fighter FK1125H Gantry Spec Body

STK: 816332

ENGINE: FUSO 6M60-9AT1 Diesel

POWER / TORQUE: 184kW / 761Nm

TRANSMISSION: 6-Speed Manual Synchromesh

CC RATING: 7,545cc

WHEELBASE: 4,270mm

CONFIGURATION: 4x2

GVM: 11,000kg

GCM: 20,000kg

SUSPENSION:

Front: Taper Leaf spring with Stabiliser Bar and Double Acting Shock Absorbers

Rear: Steel Suspension - Multi Leaf spring with Stabiliser Bar

KEY FEATURES:

• Low-height chassis
• Full air brakes for safety
• Isringhausen driver's seat
• 5T Payload capacity

BODY: Gantry Spec by LB Engineering

• 5T payload capacity
• Arms, cylinder plates, and gunnels all high tensile steel
• Deck mounted to chassis with LT400 havy vehicle cert
• Independant stabilising legs
• Certified tie-down points with LT400 load anchorage cert
• Load rated 10mm lifting chains with rubber sleeve protectors
• Lever-operated hydraulic controls on RH side of deck
• Separate "Push to  Operate"button for safe 2-handed operation
• Automatic idle-up for rapid main arm operation (may require additional module)
• 2x E-stops, one on each side of deck, with automatic PTO disengage on E-Stop
• Hydraulic pump, including fitting to PTO (excludes PTO)
• Oil reservoir with level gauge and shut-off valve
• Protected LED combination taillights
• Twin headboard work lamps , rocker switch in cab
• Storage bin for skip bin cover and / or tie-downs
• Mudguards
• Headboard / Cab protector
• Fire extinguisher, shovel and broom mounted to headboard
• Fully painted - choice of one colour.
• Two printed operator's manuals

WARRANTY:

• 30,000km service intervals
• 3 Year / 150,000km warranty

PRICE: $189,650.00 + ORC + GST
